Features
Newly Designed Frame Beam Base Chassis
The chassis of the ES model has been fundamentally revised: the overall thickness has been increased for improved rigidity, and the structures of the transformer base and other weight-bearing parts have also been redesigned to improve the instantaneous power and crispness of the sound, when compared to a conventional chassis.
Offset Screw Position Foot
Designed with an offset screw position to both eliminate the resonance point and avoid frequency-specific, vibration-inducing resonance transmission to and from the transformer, the foot also contains additional ribs for increased rigidity and improved resonance control.
Refreshed Digital Circuit Board
Metal ES-grade frames both secure the circuit board and protect it from vibration caused by speaker sound pressure. The varying fin length of the integrated heat sink reduces audible resonance uniformity while also shielding delicate circuitry from noise.
DAC enables 32-bit operations
Digital PCM signal input is processed at 32-bit and converted to analog by the DAC, while DSD signal input during direct mode is natively input to the DAC and converted to an analog signal.
Redeveloped digital section
The digital section enables all signal processing to be performed on a single chip while also providing lower impedance, increased capacitance, and better stability.
Buffer amp for DAC
DAC analog output filter circuit was designed utilizing a JFET and op-amp improvement in noise floor. The phase rotation was shifted to a higher frequency, expanding the bandwidth and improving sound clarity for wide-bandwidth sources like high-resolution audio.
Sony exclusive integrated circuit
A Sony-exclusive integrated circuit was developed to improve all amplification function on this model.
Lead free ES solder
Applying years of sound engineering and testing experience, Sony has developed an ES-grade solder. A high-purity tin base combines with small amounts of specially chosen metal elements for a unique alloy mix that enables a quality signal and exceptional sound.
Fine sound resistor
The high-quality surface-mounted resistor uses pure copper electrodes to attain high volume data conductivity for rich, vivid audio quality and is designed to address the limited space of high-density circuitry.
8K & 4K/120 HDMI Connectivity
Enjoy the latest HDMI technology with support for 8K & 4K/120 video sources. Equipped with two 8K HDMI inputs and two outputs this model is capable of delivering the most stunning picture quality and amazing clarity.
HDMI 2.1
While enabling higher quality video output and reduced latency from input devices like game consoles, HDMI 2.1 also provides support for Auto Low Latency Mode (ALLM), Variable Refresh Rate (VRR).
Supports Dolby Vision, HDR10, and Hybrid Log Gamma, and IMAX Enhanced
Enjoy dynamic, realistic picture quality with support for the leading HDR formats, including Dolby Vision, HDR10, Hybrid Log Gamma, and IMAX Enhanced.
7 HDMI Inputs/2 Outputs
This model has seven HDMI inputs with four inputs supporting full 8K & 4K/120 video sources, and two HDMI outputs that also support full 8K & 4K/120 video sources.
Support for the most advanced object-based audio formats
With support for Dolby Atmos®, Dolby Speaker Virtualization, DTS:X®, and DTS Virtual: X this model delivers a truly elevated object-based surround-sound experience.
360 Spatial Sound Mapping
Experience true immersion. Sony’s exclusive 360 Spatial Sound Mapping technology reproduces a physical sound field that can adapt to your environment and create an experience that feels like a movie theatre or concert hall.
Digital Cinema Auto Calibration IX
A new technology developed by Sony, Digital Cinema Auto Calibration IX precisely corrects the distance, angle, sound pressure, and frequency response of each speaker that’s connected to this model to create the ideal sound field for any home theater setup.
Hi-Res Audio & 360 Reality Audio
Enjoy music the way the artists truly intended with High-Resolution Audio for crystal clear precision or discover a new way of listening with 360 Reality Audio for a truly immersive live concert or studio session experience. With this model, your music comes to life like never before.
Easy Listening
Listen to all your favorite tracks, easily. This model supports audio streaming via Bluetooth®, Wi-Fi, Chromecast built-in, Spotify Connect, and Apple AirPlay®.
Works with SONOS
After a simple setup, your Sony A/V receiver will tie in seamlessly to SONOS. From the SONOS app you will be able to turn on your A/V receiver, switch to the designated input source for playback, and control the volume of your A/V receiver.
Voice Assistant Compatibility
Connect to your home’s other devices, and use voice control to operate your receiver with Google Assistant.
Music Center.
Control the Receivers from your mobile device for operations like source selection, zone control, sound field control, volume control, media playback, and voice assistant setup.
USB Front input with settings save option
Using the front mounted USB, you can easily apply system updates and during setup, save all receiver settings to a flash drive for backing up and porting over to another unit to replicate settings.
Three 12-volt triggers
Equipped with three 12-volt triggers for external peripherals, amplifiers, and more.
Three IR Repeaters
Three IR repeaters (1-in, 2-out) for external device control.
New Capacitor for High Power
In order to increase the power, a new block capacitor was developed and the design of the power amplifier has changed. Based on our long experience in the development of sound quality capacitors, we also emphasized the selection of materials and manufacturing methods to create a component that satisfies us in terms of sound quality.
New large-capacity power transformer
In order to achieve high sound quality in the large power transformer, the core material of the power transformer has been re-selected to achieve high sound quality.
Updated DSEE Ultimate for enhancing streaming music quality
Using AI-based technology, DSEE Ultimate accurately upscales audio to near-high-resolution sound quality, simulating a recording studio or concert environment.
STR-AZ7000ES Elevated sound quality and powerful amplification that meets ES standards
With 150 watts, the STR-AZ7000ES delivers cinema-like surround sound and crystal-clear music reproduction with powerful amplification.
Additional Features
Improved analog power for DAC
The DAC analog power supply uses a low- noise power supply IC to ensure that hi-fidelity performance is achieved
Updated Heat Sink.
A more uniform shape applied to the heat sink enables the amplifier circuit to withstand unwanted vibration. The heat sink bracket also shields the digital circuit from radiation, for sound quality that has more stability and clarity.
Specifications
General
Sound Channels
13.2
Power Output
Power Output: Front: 150W + 150W (8ohms, 1kHz, THD 0.9%)
Power Consumption (Max)
540 W
Total Harmonic Distortion
0.9 %
Video Compatibility
8K
Dolby Atmos
Yes
Technologies
• BRAVIA® SYNC™ (CEC Control)
• Sound Enhancement Technologies: Pure Direct, DSD Native Playback, Center Speaker Lift Up, In-Ceiling Speaker Mode
• Sound Enhancement Technologies: Pure Direct, DSD Native Playback, Center Speaker Lift Up, In-Ceiling Speaker Mode
Additional Information
• Calibration Features: DSD: Yes (Up to 2.8MHz 5.1ch), LPCM: Yes (Up to 192kHz/24 bit 7.1ch), DTS HD MA / DTS HD HR: Yes/Yes, Dolby TrueHD/Dolby Digital Plus: Yes/Yes, DTS / DTS-ES (Matrix6.1 / Discrete6.1): Yes/Yes, DTS 96/24: Yes, DTS:X: Yes, Dolby Dual Mono: Yes, Dolby Atmos: Yes
• Decoding Format for HDMI: DSD: Yes (Up to 2.8MHz 5.1ch), LPCM: Yes (Up to 192kHz/24 bit 7.1ch), DTS HD MA / DTS HD HR: Yes/Yes, Dolby TrueHD/Dolby Digital Plus: Yes/Yes, DTS / DTS-ES (Matrix6.1 / Discrete6.1): Yes/Yes, DTS 96/24: Yes, DTS:X: Yes, Dolby Dual Mono: Yes, Dolby Atmos: Yes
• Hi-Res Format: DSDIFF(DSD), DSF, WAV(LPCM), AIFF(LPCM), FLAC, ALAC
• 4K 60p 4:4:4 Support
• 3D over HDMI
• HDR (High Dynamic Range): (HDR10, Hybrid Log Gamma, Dolby Vision)
• Audio Return Channel
• 4K Output: HDMI Video Output Capability: 8K, 4K, 1080p, 1080/24p, Deep Color (up to 36 bit), Triluminous Color (xvYCC)
• HDMI™ Pass Through
• Speaker Impedance: 4ohms-16ohms
• Sound Field: 2ch Stereo, Direct, Auto Format Decoding, Multi Stereo, Audio Enhancer
• Decoding Format for HDMI: DSD: Yes (Up to 2.8MHz 5.1ch), LPCM: Yes (Up to 192kHz/24 bit 7.1ch), DTS HD MA / DTS HD HR: Yes/Yes, Dolby TrueHD/Dolby Digital Plus: Yes/Yes, DTS / DTS-ES (Matrix6.1 / Discrete6.1): Yes/Yes, DTS 96/24: Yes, DTS:X: Yes, Dolby Dual Mono: Yes, Dolby Atmos: Yes
• Hi-Res Format: DSDIFF(DSD), DSF, WAV(LPCM), AIFF(LPCM), FLAC, ALAC
• 4K 60p 4:4:4 Support
• 3D over HDMI
• HDR (High Dynamic Range): (HDR10, Hybrid Log Gamma, Dolby Vision)
• Audio Return Channel
• 4K Output: HDMI Video Output Capability: 8K, 4K, 1080p, 1080/24p, Deep Color (up to 36 bit), Triluminous Color (xvYCC)
• HDMI™ Pass Through
• Speaker Impedance: 4ohms-16ohms
• Sound Field: 2ch Stereo, Direct, Auto Format Decoding, Multi Stereo, Audio Enhancer
Network
Bluetooth
Built-In
Wi-Fi
Yes
Information
Spotify Connect
Inputs/Outputs
Information
• IR Repeat (In/Out): (1/2)
• Input and Output Terminals:
• Composite Monitor Out: 2, Opt: 2, Coax.: 1, Analog Audio In: 4, Pre Out (Subwoofer): 2, USB Front(ver) / Rear(ver): 1/0, Ethernet Port (Power over Ethernet): 1(0)
• HDMI supporting HDCP2.2 In/Out: HDMI Input supporting HDCP2.2(Front): 6(0), HDMI Output supporting HDCP2.2: 2
• Speaker Output Terminals: Front A, Center, Surround
• Input and Output Terminals:
• Composite Monitor Out: 2, Opt: 2, Coax.: 1, Analog Audio In: 4, Pre Out (Subwoofer): 2, USB Front(ver) / Rear(ver): 1/0, Ethernet Port (Power over Ethernet): 1(0)
• HDMI supporting HDCP2.2 In/Out: HDMI Input supporting HDCP2.2(Front): 6(0), HDMI Output supporting HDCP2.2: 2
• Speaker Output Terminals: Front A, Center, Surround
Accessories
Included
Calibration microphone, Calibration mic stand, FM wire antenna, AC power cord, Remote control, R03 (size-AAA) batteries, Front cover
Dimensions
Width
16.93 inch(es) / 43.0 cm
Height
7.64 inch(es) / 19.4 cm
Depth
17.32 inch(es) / 44.0 cm
Weight
48.06 lb(s) / 21.8 kg
Warranty
Warranty
5 Years
