Specifications
General
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Natural Gas
Type
Built-In
Cooktop
Burners/Elements
5
Power Output
• Burner / BTU - Left Rear 10000/7500
• Burner / BTU - Right Rear 5000/4000
• Burner / BTU - Left Front 10000/7500
• Burner/BTU - Right Front 12000/10000
• Center (Warming Zone) (BTU) 20000/12500
• Burner Simmer / BTU - Left Rear 1270
• Burner Simmer / BTU - Right Rear 670
• Burner Simmer / BTU - Left Front 1270
• Burner Simmer / BTU - Right Front 1270
• Center (Warming Zone) 1270
• Burner / BTU - Right Rear 5000/4000
• Burner / BTU - Left Front 10000/7500
• Burner/BTU - Right Front 12000/10000
• Center (Warming Zone) (BTU) 20000/12500
• Burner Simmer / BTU - Left Rear 1270
• Burner Simmer / BTU - Right Rear 670
• Burner Simmer / BTU - Left Front 1270
• Burner Simmer / BTU - Right Front 1270
• Center (Warming Zone) 1270
Burners
Sealed
Features
Technologies
20K UltraHeat™ BTU Burner
Additional Information
• Auto Re-Ignition
• Cooktop Control Type: Knobs
• Control Location: Front Center
• Heavy Duty Cast Iron Grates
• Cooktop Control Type: Knobs
• Control Location: Front Center
• Heavy Duty Cast Iron Grates
Electrical Information
Information
• 120 V
• 60Hz
• AC
• 60Hz
• AC
Accessories
Included
Conversion Kit
Dimensions
Class Width
36"
Width
36 inch(es) / 91.44 cm
Height
3.75 inch(es) / 9.53 cm
Depth
21.69 inch(es) / 55.09 cm
Weight
50.99 lb(s) / 23.13 kg
Additional Dimensions
Cut-out Dimensions (WxHxD): 33 7/8" x 3 3/4" x 19 5/8"
Shipping Dimensions
Width
40.44 inch(es) / 102.71 cm
Height
10.16 inch(es) / 25.8 cm
Depth
25.78 inch(es) / 65.48 cm
Weight
59 lb(s) / 26.76 kg
Warranty
Warranty
Parts and Labor: 1 Year
UPC
UPC#
048231344692
